Lead CNC Recommended Complete Kit – 1000x1000mm

What is a Recommended Complete Kit? Maker Store is proud to announce our new line of Recommended Complete kits, designed to perfectly match your individual application requirements. Our team of experienced engineers has carefully chosen the perfect combination of components, taking into account both performance and cost. Our Recommended Kits are pre-configured with thoughtfully selected options, from the machine’s size to all compatible parts. This extensive selection guarantees the creation of an affordable machine that excels in both capability and performance. The Lead CNC – Recommended Complete Kit – 1000x1000mm is the perfect machine to do this. Who is this CNC Machine designed for? Makers that are looking to use this machine with Light-Density Materials such as foam, cardboard, plywood, MDF, and much more. Makers that are looking for a large z-axis mid-level CNC Machine Projects up to 730mm x 810mm x 250mm What is a Lead CNC Machine?  The Lead Version 3 is a super-strong, accurate, and easy-to-assemble CNC machine made using off-the-shelf parts with easily customizable options. It has been designed to accurately cut foams, wood, plastics, and aluminum to 0.05-0.10mm accuracy or better. Functional engineering parts, toys, signs, or anything else that can be imagined, can be made on the Lead CNC Machine. With the High Z Modification for the Lead CNC – Recommended Complete Kit – 1000x1000mm, the Z-Travel is increased to approximately 250mm! This modification revolutionizes the workpieces the LEAD CNC Machine is capable of. The High Z Mod uses dual extrusions for the X-Axis and connected gantry carts to increase the strength and stability while decreasing flex across the X-Z Axis. Practical Examples of the Lead CNC’s Masterpieces! Imagine the possibilities that await you with the Lead CNC – Recommended Complete Kit – 1000x1000mm. Craft breathtaking wooden signs that add a touch of elegance to any space, precisely engrave personalized designs on acrylic trophies and awards, or even mill and cut aluminum and other soft metals. The Lead CNC allows you to transform raw materials into unique works of art and practical creations, limited only by your imagination. Here is an example of what our imagination allowed us to make!  Which materials can be used with this machine? With the Lead CNC – Recommended Complete Kit – 1000x1000mm, you gain access to a vast array of materials that can be effortlessly cut and engraved. From delicate woods to intricate Aluminium and a range of other soft metals, this machine empowers you to push the boundaries of your imagination. Create stunning signs, personalized home decor, intricate jewelry, precise prototypes, and so much more! The most common materials paired with the Lead CNC Machine but not limited to are: Structural Foam Aluminium MDF Plastics Plywood Soft Metals Machine Configuration Workable area: 730x 810x250mm CNC Controller: xPro V5 CNC Controller Spindle: 1.5kw Air Cooled Spindle ER16 Stepper Motors: 4 x Nema 23 Stepper Motor – High Torque – 2.45Nm – 6.35mm Shaft Cable Management System: 15×30 Drag Chain Bundle Touch Probe: XYZ Touch Probe xPRO V5 CNC Controller The xPRO V5 is the most recommended controller for starters due to its plug-and-play nature. The xPRO V5 does not require a system with multiple power supplies or external stepper drivers. These features on the xPRO V5 make it the most user-friendly controller offered at Maker Store.       The xPRO V5 CNC Controller is a cutting-edge electronic control system specifically designed for CNC machines. It serves as the brain of the CNC system, providing control and communication between the computer or control software and the various components of the machine. The xPRO V5 CNC Controller offers advanced features and capabilities to enhance the performance and precision of your CNC machine. The controller provides interfaces for limit switches, homing sensors, and other essential peripherals, ensuring accurate positioning and safe operation of the machine. Whether you’re working on intricate woodworking projects, creating precise metal parts, or exploring the possibilities of 3D carving, the xPRO V5 CNC Controller provides the control and precision you need to bring your designs to life. 400W ER16 Spindle The 400W spindle is capable of cutting wood, plastic, structural foam, or carbon fiber; it is also capable of engraving soft metals, such as aluminum. Powerful enough for hobby applications, this spindle would best suit a small CNC machine and is a perfect entry-level spindle. Our 400W spindle motor ensures smooth and efficient operation, reducing vibrations and minimizing noise for a more enjoyable working environment. It has high-quality bearings and sturdy construction that guarantee long-lasting durability, making it a reliable choice for both hobbyists and professionals alike. Whether you’re carving intricate patterns, drilling precise holes, or engraving intricate details, this motor is up to the task, of delivering exceptional performance with every operation. Stepper Motors (Motion Motors) – 2.45Nm   With a torque rating of 2.45Nm, this stepper motor provides ample power to tackle a wide range of applications. From precision positioning to high-speed machining, it offers the strength and stability needed to handle demanding tasks with ease. Built with high-quality components, our Nema 23 Stepper Motor – High Torque – 2.45Nm – 6.35mm Shaft is designed for longevity and reliability. It features precise windings and durable bearings that ensure consistent performance over extended periods of operation. This motor is built to withstand the rigors of daily use, making it an excellent choice for both professional workshops and hobbyist projects.       XYZ Touch Probe With its user-friendly design, the XYZ Touch Probe simplifies tool and workpiece setup. Probing specific points or edges enables the machine to precisely determine the position of the tool or workpiece. This eliminates the need for manual measurements and ensures consistent setups across multiple machining operations. This saves valuable time and improves overall workflow efficiency.         Recommended Software Packages With these machines, you will require two pieces of software to create your projects. In simple words, the first software (CAD/CAM) will be responsible for creating the cut files (gcode file), while the second software (gCode Sender) is responsible for reading the gcode files. CAD/CAM (First Software) Option 1 – Fusion 360 – FREE for non-commercial purposes Fusion 360 is a powerful and comprehensive software solution specifically designed for CNC machining. It provides a wide range of tools and features to support the entire CNC workflow, from design and simulation to toolpath generation and machine control. Fusion 360 allows you to create and design your CNC projects in a 3D environment, allowing you to visualize and model your ideas with precision. Fusion 360 also offers a powerful CAM (Computer-Aided Manufacturing) module that allows you to generate toolpaths for your CNC machine.   Option 2 – Carveco – Subscription-Based Software- Not Included in this Offer Carveco Software is a leading software solution specifically designed for CNC machining, woodworking, and engraving applications. It offers a comprehensive set of tools and features that empower users to bring their creative visions to life with precision and ease. With Carveco Software, you can create intricate designs and models in a user-friendly and intuitive 3D environment. The software provides powerful modeling and sculpting tools that allow you to create organic shapes, complex geometries, and intricate details for your CNC projects. Whether you’re designing furniture, decorative pieces, signage, or artwork, Carveco Software offers the flexibility and capabilities to bring your ideas to reality. One of the key features of Carveco Software is its advanced toolpath generation. The software offers a variety of machining strategies, including 2D profiling, 3D roughing and finishing, pocketing, and engraving. It allows you to optimize toolpaths for efficient material removal, achieve smooth surface finishes, and control cutting parameters for different materials and CNC machines. Option 3 – Vectric VCarve – Desktop – Not included in this offer Vectric VCarve Desktop software is a professional-grade solution designed specifically for CNC routing and engraving projects. It offers a comprehensive set of features and tools that empower users to create intricate designs, generate toolpaths, and control their CNC machines with precision and efficiency. With VCarve Desktop, you can create detailed 2D and 2.5D designs using a user-friendly and intuitive interface. The software provides a range of drawing and editing tools, allowing you to create or import vector graphics, add text, and manipulate shapes to create unique designs. Whether you’re working on signage, woodworking projects, or personalized engravings, VCarve Desktop offers the flexibility to bring your ideas to life. g-Code Sender Software (Second Software) CNCjs 1.9.22 (Recommended) – FREE   CNCjs is an open-source software platform specifically designed for controlling and monitoring CNC machines. It offers a range of features and functionalities that make it a popular choice among CNC enthusiasts, hobbyists, and professionals. With CNCjs, you can easily connect and communicate with your CNC machine using a computer or a Raspberry Pi. The software provides a user-friendly web-based interface. The interface allows you to control your machine remotely from any device with a web browser. It supports various communication protocols, such as USB, Ethernet, and Wi-Fi, ensuring compatibility with a wide range of CNC machines.   Looking for something more customizable? We’ve got you covered! Here at Maker Store, we understand that “one size fits all” does not work for everybody. For that reason, we do not lock you into one type of machine, or one type of electronic system. Click HERE to select the configuration that you want! If you have any questions! Email: [email protected] Phone: (580) 239-9562 CREDITS/SOURCE This is the Maker Store Lead CNC design is an offspring inspired by the original Open Source Lead CNC Machine designed by Mark Carew and the design is licensed under CC – Attribution – CC BY.
